Cincinnati Milacron Heald 261-20

Rotary Surface Grinder
Price on Request
Back to Products
Machine Serviced & Checked

Fully inspected and maintained by certified technicians before delivery.

Shipping Across US Mainland

Fast and reliable transport options available within the continental USA.

12-Month Warranty

All machines come with a full one-year warranty, giving you added peace of mind and assurance that your investment is protected.

Best Price Direct from Owner

No resellers involved — you get the most competitive price straight from us.

Product Description

This high-precision rotary surface grinder is designed for efficient flat grinding of a wide range of materials. Built by Cincinnati Milacron/Heald, the 261-20 offers durable construction, smooth operation, and reliable accuracy for production or toolroom environments.

Key Specifications:

  • Magnetic Chuck Diameter: 21"

  • Usable Chuck Life: 5/8"

  • Max. Swing Inside Splash Guard: 18.5"

  • Spindle Centerline to Chuck Distance: 6" – 17.5"

  • Grinding Wheel Size: 14" Ø × 1" Face × 5" Bore

  • Wheel Speed Range: 50 – 225 RPM

  • Grinding Wheel Drive Motor: 15 HP AC

  • Vertical Travel of Table: 12"

  • Grinding Stroke: 8"

  • Grinding Speed: 0 – 12 FPM

  • Runout: 35 FPM

This machine combines solid horsepower with precision grinding capability, making it suitable for demanding surface finishing applications.
